Name: DIN Rail 60W, Single Output
Brand: Acro Engineering Incorporation
SKU: ADS060F Series

DIN Rail 60W, Single Output

Input Voltage:100~240VAC/120~370VDC
Rated Output Voltage: +12V、+24V、+48V
Rated Output Power: 60W
Dimension:100(D)x36.5(W)x107(H) mm

Model : ADS060F Series

Q'ty :

This series includes ADS060-24F and ADS060-48F that with 100-240VAC universal input range and complete
protection design. The DIN rail / bracket mounting solution and compact dimensions let the models be suitable
for distribution board that supplying power source for PLC, HMI and I/O devices. Long life aluminum electrolytic
capacitor, 100% burn-in testing and moisture proof coating to let the industrial power supply series be rugged
power supply, robust power supply and heavy duty power supply. All models are RoHS compliance, CE marking
and meet UL508 requirement.

DATASHEET:

INPUT
Input voltage:100~240VAC/120~370VDC
Input frequency:47~63Hz
Inrush current:22A/115VAC
(Cold start) 44A/230VAC

OUTPUT
Hold-up time (Full load@230VAC):20mS Min.
Over voltage protection:Autorecovery
Overload protection:Power limited
Short circuit protection:Autorecovery

Model	Output Voltage Adjustment	Loading			Ripple Noise	Eff.	Over Voltage Protection	MOQ
Model	Output Voltage Adjustment	Min.	Rated	Max.	Ripple Noise	Eff.	Over Voltage Protection	MOQ
ADS060-24F(T/E)	+24VDC±10%	0A	2.5A	2.5A	150mVp-p	84%	27~30VDC	300
ADS060-48F(T/E)	+48VDC±10%	0A	1.25A	1.25A	250mVp-p	84%	52~57VDC	300

Features

Innovative design of industrial-grade power supply rail

Natural convection air cooling

High voltage protection

Current overload protection

Short circuit protection

Din rail / retainer lock with fixed protection

Selective warning signals (dry contact) / redundancy

High power density

High reliability

Small size, high efficiency, low cost

Comply with RoHS / UL / CE Standard

3-year quality warranty

Operating Environment

Operating temperature: -40 to 50 degrees

Operating humidity: non-condensing 5% to 95% relative humidity

Application
Designed for industrial applications. With the rugged and thoughtful fixed design, you can mount the
Power Supply on TS35 DIN rail, wall, or any surface. Designing for the size and wiring distribution of
the power chassis, it saves a lot of space and be more convenient to make wiring distribution.
This product is suitable for automatic control systems, factory automation, industrial control,
instrumentation equipment, electromagnetic actuators and other DC motor load and according to the
latest requirements and standards designed.
