Battery Charger 72W, Single Output

Input Voltage:100~240VAC/120~370VDC
Rated Output Voltage: +12V、+24V
Rated Output Power: 72W
Dimension:110(H)X121(D)X56(W)mm
Model : AD1072CF Series

Our Lead-Acid Battery Chargers are used by electric vehicle and medical facilities appliances etc. These Lead-Acid Battery Chargers have built-in smart 5-step charging control accomplish the missions. The Lead-Acid Battery Chargers not only charging a battery but also lengthen life cycle and advance efficiency of battery.
INPUT
Input voltage:100~240VAC/120~370VDC
Input frequency:47~63Hz
Inrush current:22A/115VAC
(Cold start) 44A/230VAC

OUTPUT
Hold-up time (Full load@230VAC):20mS Min.
Over voltage protection:Autorecovery
Overload protection:Power limited
Short circuit protection:Autorecovery
Reverse polarity protec:Autorecovery


DATASHEET:

Model

Charging Voltage

Charging Current

Line Reg.

Load Reg.

Eff.

Over Voltage Protection

MOQ

Boost

Float

AD1072C-12F

14.7VDC

13.6VDC

6.0A Max.

±1%

±1%

81%

18~22VDC

300

AD1072C-24F

29.4VDC

27.2VDC

3.0A Max.

±1%

±1%

82%

33~37VDC

300


Features

High power density

Universal input range

Convection cooled

RoHS compliance

3 - year warranty

Great reliability

DIN rail / Wall bracket mounting solution

Over voltage protection

Overload protection

Short circuit protection

Reverse polarity protetion

3-stage charging control



Operating Environment
Operating temperature: -40 to 50 degrees
Operating humidity: non-condensing 5% to 95% relative humidity

Application
Smart 3-step charging control accomplish the charger not only charging a battery but lengthen life cycle and advance efficiency of battery. Switching mode design features high power factor, high efficiency and lightweight construction. Charging voltage ranged from 12VDC to 48VDC, Wattage ranged from 90W to 500W. All models are compliant to RoHS.
